Baldor Servo Motor

AC Brushless Servo N-Series Motors



Our AC brushless servo motors BSM N-series provide industrial motion control applications with low inertia to attain the highest acceleration capability - to allow you to position rapidly. The BSM N-series is used in the world's fastest machines and demanding applications.

The N-Series brushless servo motors provide a rugged, durable design with high energy Neodymium-Iron-Boron magnetics. This series provides continuous stall torque capability ranging from 3.9 Lb-In (0.45 N-m) to 354 Lb-In (40 N-m). Peak torque capability is nominally 4 times continuous. This series has the lowest inertia to provide the maximum torque per package size.


The BSM motor has been time proven over the years. The BSM N-series is used in the world's fastest machines, in industrial motion control applications such as: indexers, form/fill/seal, flying shears, cut-to-length, robotics, insertion, packaging, capping machines, laser trimming, marking/labeling and many other demanding applications.

Features

  • Low inertia rotor design with Neo magnets - 5 standard frame sizes to choose
  • Acceleration torques from 16 Lb-In (1.8 N-m) to 1400 Lb-In (160 N-m)
  • High output torque at low speed - continuous 4 Lb-In (0.4 N-m) to 354 Lb-In (40 N-m)
  • Inertia range .00006 - .034 Lb-In-s2 (.067 - 38 Kg-cm2)
  • Standard windings for 160, 300, 650 bus volts- customs available
  • Dependability designed in the high 155°C design
  • Premium 200°C moisture resistant, multi-coated wire for reliability
  • Extra high insulated stator for high voltage and current spike protection
  • Superior bearings with Exxon PolyrexEM TM polyrex grease to provide 4 times greater life
  • Rugged industrial construction to provide quality throughout the design
  • Stock and customs available - IEC/NEMA designs
  • UL/CSA/CE



AC Brushless Servo C-Series Motors

The BSM C-series provides industrial motion control machines with an AC brushless servo motor with “higher” inertia – thus providing an excellent match for equipment requiring “higher” inertial matching. The goal of this series design was to increase torque while reducing package size (comparing to previous series). The result was a torque increase of up to 50% in some models, with a package reduction of up to 2 inches/50mm.

The BSM C-series provides continuous stall torques ranging from 10 Lb-In (1.2 N-m) to 1062 Lb-In (120 N-m). Peak torques are 3 times continuous. The C-Series provides an economical package best used in applications with higher load inertias.



.
The BSM C-series provides continuous stall torques ranging from 10 Lb-In (1.2 N-m) to 1062 Lb-In (120 N-m). Peak torques are 3 times continuous. The C-Series provides an economical package best used in applications with higher load inertias.

Features

  • More torque in smaller package than previous designs
  • Acceleration torques from 32 Lb-In (3.6 N-m) to 3186 Lb-In (360 N-m)
  • High output torque at low speed – continuous 10 Lb-In (1.2 N-m) to 1062 Lb-In (120 N-m)
  • Inertia range .0016 - .038 Lb-In-s2 – 0.57 Lb-In- s2 (1.8 - 42.6 – 644 Kg-cm2)
  • Standard windings for 160, 300, 600 bus volts- customs available
  • Premium 200°C moisture resistant, multi-coated wire for reliability
  • Extra high insulated stator for high voltage and current spike protection
  • Superior bearings with Exxon PolyrexEM TM polyrex grease to provide 4 times greater life
  • Rugged industrial construction to provide quality throughout the design
  • Stock and customs available - IEC/NEMA designs
  • UL/CSA/CE

AC Brushless Stainless Steel Servo Motors

ABB's totally stainless steel SSBSM series of AC brushless servo motors are designed for industrial applications such as food, liquid, pharmaceutical, and other motion control applications requiring washdown, and high hygiene motors. They may be applied in harsh, corrosive environments. These motors are designed to handle IP67 and withstand 1500 psi washdown conditions.

These stainless steel servo motors are offered in standard and low inertia designs for best machine inertial matching. Included in this quality design are lazer etched nameplate, FDA shaft seal, environmental protected stator with premium moisture resistant wire, and internal thermal over temperature protection. ABB’s SSBSM products are designed to be durable.

Features

  • All stainless steel construction 304 housing, 416 shaft – suitable for pharmaceutical and food processing
  • Watertight – sealed to IP67 and 1500 psi for heavy duty washdown applications
  • Non-corrosive housing – provides protection in harsh environment
  • FDA shaft seal - complies with food industry standards
  • BISSC – complies with Baking Industry Sanitation Standards Committee
  • Laser etched nameplate – no areas for bacteria to cling
  • Potted stator – provides environmental protection and high voltage protection
  • UL rated for 130 C rise – to provide extra high insulation/safety
  • Internal thermal switch – supplies safeguard against overheating
  • Exxon Polyrex EM Polyurea grease - proven to provide 4 times greater life
  • Standard & low inertia models – choose the best for the application
  • BISSC/UL/CSA/CE –agency approvals
